GYFTY Outdoor Optical Cable

Outdoor non-metallic optical cable for aerial and duct installations. Environmentally friendly sheath, excellent bending radius, and stable transmission over long distances.

Request a Quote

Product Features

Flexible & Durable

Environmentally friendly PE sheath ensures durability and flexibility.

Long Distance

Low attenuation for stable long-distance signal transmission.

Wide Applications

Supports aerial and duct installations efficiently.

High Strength

Allowable tensile strength for both short-term and long-term use.

Technical Specifications

Brand	DGNX
Outer Jacket Material	Environmentally Friendly PE Sheath
Product Name	Outdoor Non-Metallic Optical Cable GYFTY
Length	3000m
Fiber Count	4–288 Cores
Wavelength	1310–1550nm
Bending Radius (Static/Dynamic)	12.5D / 25D (mm)
Allowable Tensile Strength (Long-term/Short-term)	400 / 1000N
Allowable Crush Resistance (Long-term/Short-term)	300 / 1000 (N/100mm)
Application	Aerial / Duct Installation
Operating Temperature	-40°C to +85°C
